Model → SW03 Rated Torque → 120 Nm (S3 40%) Braking Torque → 2x180 Nm Power Range (min - max) → 0,8 - 6,4 kW Static Load → 23,5 kN - 2400 kg Maximum Weight → 121 kg Motor Rated Voltage → 360 V - 208 V
Model → SW05 Rated Torque → 160 Nm (S3 40%) Braking Torque → 2x180 Nm Power Range (min - max) → 1,0 - 8,5 kW Static Load → 29,4 kN - 3000 kg Maximum Weight → 129 kg Motor Rated Voltage → 360 V - 208 V
Model → SW07 Rated Torque → 200 Nm (S3 40%) Braking Torque → 2x220 Nm Power Range (min - max) → 1,3 - 10,7 kW Static Load → 29,4 kN - 3000 kg Maximum Weight → 143 kg Motor Rated Voltage → 360 V - 208 V
