Max Static Load – 5200 kg (SH190) – 6000kg (SH190TS)
Max Rated Load in 1:1 – 1800kg
VVVF Power Range: 4,2 … 30kW (50Hz) –4,7 … 33kW (60Hz)
AC2 Power Range: 4,2 … 16,5 kW (50Hz) – 4,7 … 18kW (60Hz)
Car Speed – 0,4 … 3,7m/s (50Hz) – 0,5… 4,5m/s (60Hz)
Traction Sheaves – 520 … 750mm
Gear Ratio – 1/40; 1/51; 1/62; 2/59; 3/47
Oil Capability – 11,5l
Gear Weight – 620kg (SH190) – 645kg (SH190TS)
