Max Static Load – 2600 kg
Max Rated Load in 1:1 – 550kg
VVVF Power Range: 2,7 … 5,5kW (50Hz) – 4 … 6kW (60Hz)
AC2 Power Range: 2,7 … 5,5 kW (50Hz) – 4 … 6kW (60Hz)
Car Speed – 0,3 … 2,2m/s (50Hz) – 0,6… 2,6m/s (60Hz)
Traction Sheaves – 320 … 600mm
Gear Ratio – 1/52; 1/45; 1/43; 2/53; 2/43
Oil Capability – 3,8l
Gear Weight – 240kg
